09180-00842 TIMER ASSY, AUTOMA Denso Cross




Information timer assy, automa

09180-00842 TIMER ASSY, AUTOMA
Rating:
26
Buy TIMER ASSY, AUTOMA 09180-00842 genuine, new aftermarket engine parts with delivery

Scheme ###:

TIMER ASSY, AUTOMA
000. [01] 09180-00842 TIMER ASSY, AUTOMA 22510-1061
001. [01] 09181-00461 HUB ASSY, TIMER 22513-1120
002. [01] 09184-00640 FLANGE, TIMER DRIV 22513-1210A
003. [02] 09183-60122 WEIGHT SUB-ASSY, T 22514-1040
004. [01] 09185-60310 COVER, TIMER 22512-1010A
005. [01] 94915-00980 SEAL, OIL 22827-1080A
009. [02] 94904-04471 BOLT, HEXAGON 22815-2390A
010. [02] 09022-20080 WASHER, FUEL PIPE 22847-1330A
011. [04] 09188-40011 SUPPORT, TIMER SPR 22517-1110A
012. [04] 09181-90700 SPRING, TIMER
013. [4C] 94901-34210 WASHER, PLATE, SK 22885-1690A
013. [4C] 94901-34200 WASHER, PLATE, SK 22885-1680A
013. [4C] 94901-34190 WASHER, PLATE, SK 22885-1670A
013. [4C] 94901-34180 WASHER, PLATE, SK 22885-1660A
013. [4C] 94901-34170 WASHER, PLATE, SK 22885-1650A
014. [02] 09188-30010 BUSHING, TIMER ROL 22521-1020
015. [02] 09188-20010 ROLLER, TIMER 22522-1010A
016. [02] 94901-15070 WASHER, STEEL PLAT 22867-1120A
017. [01] 09188-50020 SCREW, TIMER OIL S 22845-1120A
018. [01] 09083-90040 PACKING 22847-2410A
018. [01] 09083-90020 PACKING 22847-1190A
019. [01] 94914-01560 O-RING 22817-1150A
022. [01] 94904-31500 BOLT, STUD 22857-1010
023. [01] 09031-70060 PLUG, SCREW 22845-1060A
025. [02] 94901-20870 WASHER, CAP 22867-1130A
026. [01] 94901-81500 WASHER, COPPER PLA 22847-1120A

Include in #3:

09180-00842 as TIMER ASSY, AUTOMA

Cross reference number



Part num Firm num Firm Name
09180-00842  22510-1061  TIMER ASSY, AUTOMA




Information:

1. Remove oil supply tube (1) and suction bell and tube (2). 2. Remove bolts (3) that hold the oil pump to the cylinder block, and remove oil pump (4). The following steps are for installation of the oil pump.3. Put oil pump (4) in position on the cylinder block. Install the bolts that hold the oil pump to the cylinder block.4. Put clean engine oil on the O-ring seals of the tubes.5. Install oil supply tube (1) and suction bell and tube (2).End By:a. install oil panDisassemble Oil Pump
Start By:a. remove oil pump1. Remove the bolt and washer that hold the gear on the shaft. 2. Use tooling (A), and remove drive gear (1) from the shaft. Remove the key from the shaft. 3. Remove retainer (3) for the bypass valve.4. Remove the spring and bypass valve.5. Remove cover (2) from the pump body. 6. Use tooling (B), and remove the bearings from the cover. 7. Remove gears (5) and (6) from pump body (4).8. Use tooling (B), and remove the bearings from the pump body (4).Assemble Oil Pump
1. Use tooling (B), to install the bearings in the pump body. Install the bearings so the joint in the bearings is 30° 15° for the center line of the oil pump outlet passage (7). 2. Install idler gear (5) and drive gear (6) in the oil pump body. Put clean engine oil on the bearings and the gears. 3. Use tooling (B), and install the bearings in cover (2). Install the bearings so the joint in the bearings is 30° 15° for the center line of the bearing bores toward oil pump outlet passage (7).4. Install bypass valve (8), spring (9) and the retainer.5. Install the key on the shaft. 6. Install gear (1) on the shaft. Install the washer and bolt that hold the gear on the shaft. BE sure the pump turns freely after assembly.End By:a. install oil pump
