Information timer assy, automa
Rating:
Scheme ###:
| 000. | [01] | 09180-00650 | TIMER ASSY, AUTOMA | 22510-1350 |
| 001. | [01] | 09181-00771 | HUB ASSY, TIMER | 6 306 1404 00 |
| 002. | [02] | 09181-90020 | SPRING, TIMER | 6 056 1400 90 |
| 003. | [2C] | 94901-33760 | WASHER, PLATE, SK | 22881-2350A |
| 003. | [2C] | 94901-33770 | WASHER, PLATE, SK | 22881-2360A |
| 003. | [2C] | 94901-33780 | WASHER, PLATE, SK | 22881-2370A |
| 003. | [2C] | 94901-33790 | WASHER, PLATE, SK | 22885-1870A |
| 003. | [2C] | 94901-33800 | WASHER, PLATE, SK | 22885-1880A |
| 004. | [01] | 94914-01770 | O-RING | 22813-1630A |
| 005. | [02] | 09183-70011 | WEIGHT, TIMER | 22514-1190 |
| 006. | [01] | 09184-00211 | FLANGE, TIMER DRIV | 22513-1450 |
| 007. | [01] | 94915-01060 | SEAL, OIL | 6 306 1404 40 |
| 008. | [01] | 94915-01070 | SEAL, OIL | 22827-1320A |
| 009. | [01] | 09185-60172 | COVER, TIMER | |
| 010. | [02] | 94901-81020 | WASHER, COPPER PLA | 22847-1300A |
| 011. | [02] | 09186-20010 | SCREW, TIMER HUB | 22865-1270A |
Include in #3:
Cross reference number
| Part num | Firm num | Firm | Name |
| 09180-00650 | 22510-1350 | TIMER ASSY, AUTOMA | |
| 22510-1350 | HINO | TIMER ASSY, AUTOMA |
Information:
Obtain Oil Sample Every 250 Hour Interval (T & TA) or Every 500 Hour Interval (NA).Obtain S O S samples at regularly scheduled intervals to monitor the condition and maintenance requirements of your engine. Each oil sample should be taken when the oil is warm and well mixed to ensure that the sample is representative of the oil in the engine crankcase.Consult your Caterpillar dealer for complete information and assistance in establishing an S O S analysis program for your engine(s).S O S Analysis
S O S analysis is composed of three basic tests: * Wear Analysis* Chemical and Physical Tests* Oil Condition Analysis Wear analysis is performed with an atomic absorption spectrophotometer to monitor component wear by identifying and measuring concentrations, in parts per million, of wear elements present in the oil. Based on known normal concentration data, maximum limits of wear elements are established. Impending failures can be identified when test results deviate from concentration levels established as acceptable, based on normal wear. Chemical and physical tests detect the presence of water, fuel and glycol (antifreeze) in the oil and determine whether or not their concentrations exceed established maximum limits. Oil condition is evaluated with infrared analysis. This test determines the presence and measures the amount of contaminants such as soot, sulfur products, oxidation, and nitration products in the oil. Infrared analysis can also assist in customizing (reducing, maintaining or extending) oil change intervals for particular conditions and applications.Infrared analysis should always be accompanied by wear element analysis and chemical and physical tests to assure accurate diagnosis. Infrared analysis must be used to determine oil change intervals. S O S analysis must include Infrared (IR) in the analysis.The test results of the oil samples will then be used as a basis for determining the oil change interval for your engine, giving you the ultimate time between oil changes without the risk of engine damage.Refer to Caterpillar pamphlet Listen To Your Oil (PEDP1129) for information and benefits of S O S analysis.
S O S analysis is composed of three basic tests: * Wear Analysis* Chemical and Physical Tests* Oil Condition Analysis Wear analysis is performed with an atomic absorption spectrophotometer to monitor component wear by identifying and measuring concentrations, in parts per million, of wear elements present in the oil. Based on known normal concentration data, maximum limits of wear elements are established. Impending failures can be identified when test results deviate from concentration levels established as acceptable, based on normal wear. Chemical and physical tests detect the presence of water, fuel and glycol (antifreeze) in the oil and determine whether or not their concentrations exceed established maximum limits. Oil condition is evaluated with infrared analysis. This test determines the presence and measures the amount of contaminants such as soot, sulfur products, oxidation, and nitration products in the oil. Infrared analysis can also assist in customizing (reducing, maintaining or extending) oil change intervals for particular conditions and applications.Infrared analysis should always be accompanied by wear element analysis and chemical and physical tests to assure accurate diagnosis. Infrared analysis must be used to determine oil change intervals. S O S analysis must include Infrared (IR) in the analysis.The test results of the oil samples will then be used as a basis for determining the oil change interval for your engine, giving you the ultimate time between oil changes without the risk of engine damage.Refer to Caterpillar pamphlet Listen To Your Oil (PEDP1129) for information and benefits of S O S analysis.
