09130-05844 GOVERNOR ASSY, MEC Denso Cross




Information governor assy, mec

09130-05844 GOVERNOR ASSY, MEC
Rating:
58
Buy GOVERNOR ASSY, MEC 09130-05844 genuine, new aftermarket engine parts with delivery

Scheme ###:

GOVERNOR ASSY, MEC
000. [01] 09130-05844 GOVERNOR ASSY, MEC 22310-5910
001. [01] 09131-00250 HOUSING SUB-ASSY, 22301-1610A
001. [01] 09131-00320 HOUSING SUB-ASSY,
001-001. [01] 09101-60020 BUSHING, BEARING 22322-1180A
002. [01] 09145-00851 COVER ASSY, GOVERN 22380-2100A
002. [01] 09145-00950 COVER ASSY, GOVERN
003. [01] 09133-01561 FLYWEIGHT ASSY 22360-1890A
003-001. [01] 09137-00101 FLYWEIGHT SUB-ASSY 22360-1900A
003-005. [01] 09134-00081 BUSHING ASSY, CAMS 22322-2380A
003-006. [02] 09137-70371 SEAT, GOVERNOR SPR 22351-1920A
003-007. [02] 09136-30050 SEAT, GOVERNOR SPR 22351-1810A
003-008. [02] 09139-30100 GUIDE, SPRING 22385-2440A
003-009. [02] 09091-81710 SPRING, MECHANICAL 22341-2160A
003-010. [02] 09138-91280 SPRING, IDLING 22411-2660A
003-011. [02] 09139-50050 NUT, ADJUSTING 22825-2310A
003-012. [01] 09140-50090 BUSHING, GUIDE 22322-2230A
003-013. [01] 09140-10040 BOLT, BELLCRANK 22815-1940A
003-013. [01] 09140-10061 BOLT, BELLCRANK 22815-3600A
003-014. [02] 91418-06161 BOLT, W/WASHER 22815-1380A
003-014. [02] 94904-78260 BOLT, W/WASHER 22815-3410A
003-015. [06] 09133-70100 DAMPER, FLYWEIGHT 22385-1900A
003-016. [02] 09138-91290 SPRING, IDLING 22411-2670A
003-017. [02] 09139-10620 SPRING, SPEED CONT 22321-3920A
003-018. [02] 09139-10560 SPRING, SPEED CONT 22321-2950A
003-019. [02] 90160-06051 NUT, HEXAGON 22825-1480A
003-019. [02] 09089-40101 E-RING 22456-1260A
003-020. [01] 09140-30010 WASHER, LOCK 22863-1190A
003-021. [6C] 09140-30560 WASHER, LOCK 22863-2090A
003-021. [6C] 09140-30570 WASHER, LOCK 22863-2100A
003-021. [6C] 09140-30640 WASHER, LOCK 22863-2110A
003-021. [6C] 09140-30650 WASHER, LOCK 22863-2120A
003-022. [6C] 09140-30690 WASHER, LOCK 22863-2080A
003-022. [6C] 09140-30680 WASHER, LOCK 22863-2070A
003-022. [6C] 09140-30610 WASHER, LOCK 22863-2060A
003-022. [6C] 09140-30600 WASHER, LOCK 22863-2050A
003-023. [6C] 09140-30540 WASHER, LOCK 22863-2010A
003-023. [6C] 09140-30550 WASHER, LOCK 22863-2020A
003-023. [6C] 09140-30620 WASHER, LOCK 22863-2030A
003-023. [6C] 09140-30630 WASHER, LOCK 22863-2040A
003-024. [6C] 09140-30670 WASHER, LOCK 22863-2000A
003-024. [6C] 09140-30660 WASHER, LOCK 22863-1990A
003-024. [6C] 09140-30590 WASHER, LOCK 22863-1980A
003-024. [6C] 09140-30580 WASHER, LOCK 22863-1970A
003-025. [01] 94901-33970 WASHER, PLATE, SK 22885-1740A
003-025. [02] 09140-30800 WASHER, LOCK 22863-2450A
003-026. [01] 09133-40100 NUT, ROUND 22535-1120A
003-027. [1C] 09133-10200 SHIM 22885-2540A
003-027. [1C] 09133-10210 SHIM 22885-2550A
003-027. [1C] 09133-10220 SHIM 22885-2560A
003-027. [1C] 09133-10230 SHIM 22885-5950A
003-027. [1C] 09133-10240 SHIM 22885-5960A
003-027. [1C] 09133-10250 SHIM 22885-5970A
003-027. [1C] 09133-10190 SHIM 22885-2530A
003-027. [1C] 09133-10180 SHIM 22885-2520A
003-027. [1C] 09133-10170 SHIM 22885-2510A
003-027. [1C] 09133-10110 SHIM 22885-2450A
003-027. [1C] 09133-10120 SHIM 22885-2460A
003-027. [1C] 09133-10130 SHIM 22885-2470A
003-027. [1C] 09133-10140 SHIM 22885-2480A
003-027. [1C] 09133-10150 SHIM 22885-2490A
003-027. [1C] 09133-10160 SHIM 22885-2500A
006. [01] 09142-60081 SLIDER 22349-1131A
007. [01] 09143-00150 LEVER ASSY, FLOATI
007. [01] 09143-00161 LEVER ASSY, FLOATI
007-001. [01] 09143-60290 LEVER SUB-ASSY, FL
007-001. [01] 09143-60300 LEVER SUB-ASSY, FL
007-002. [01] 09169-50041 STOPPER SUB-ASSY, 22357-1091A
007-003. [01] 09094-00620 LEVER SUB-ASSY, CO
007-003. [01] 09094-00630 LEVER SUB-ASSY, CO
007-004. [01] 09104-21480 SPRING, RETURN
007-004. [01] 09104-22070 SPRING, RETURN
007-005. [01] 09104-21470 SPRING, RETURN
007-005. [01] 09104-22050 SPRING, RETURN
007-006. [02] 09089-40020 E-RING 22873-1390A
007-007. [2C] 94901-31390 WASHER, PLATE, SK 22885-1920A
007-007. [2C] 94901-32370 WASHER, PLATE, SK 22885-1930A
007-007. [2C] 94901-33960 WASHER, PLATE, SK 22885-1030A
007-007. [2C] 94901-35080 WASHER, PLATE, SK 22885-1270A
007-007. [2C] 94901-35090 WASHER, PLATE, SK 22885-1280A
008. [01] 09098-00341 SHACKLE SUB-ASSY 22045-1110A
009. [01] 09148-00380 ARM ASSY, GUIDE 22307-2580A
009-001. [01] 19089-00790 OVER-HAUL KIT, GOV
011. [01] 94915-02522 SEAL, OIL 22827-1530A
012. [01] 09101-70380 PLATE, CAM 22369-2800A
013. [01] 09104-20600 SPRING, RETURN 22341-1710A
014. [03] 09089-40020 E-RING 22873-1390A
015. [02] 09156-00021 LEVER SUB-ASSY, SU 22350-1190A
016. [01] 09156-30050 SHAFT, LEVER SUPPO 22358-1410A
017. [01] 09129-01180 LEVER SET 22350-2270A
017-001. [01] 09129-10331 LEVER SET
017-002. [01] 09107-14500 LEVER, ADJUSTING 22415-2180A
017-003. [02] 91418-06201 BOLT, W/WASHER 22815-1290A
017-004. [01] 09107-15410 LEVER, ADJUSTING
019. [02] 09116-70110 PLUG, SCREW 22845-1250A
021. [01] 94913-00030 KEY, WOODRUFF 22891-1060A
022. [01] 09082-10310 STOPPER 22865-1360A
023. [01] 09116-90024 NUT 22825-1890A
024. [01] 91418-06201 BOLT, W/WASHER 22815-1290A
025. [01] 94904-71750 BOLT, W/WASHER 22815-1490A
026. [02] 94904-07220 BOLT, HEXAGON 22815-2950A
027. [02] 90160-06051 NUT, HEXAGON 22825-1480A
028. [02] 94904-71760 BOLT, W/WASHER 22815-1860A
029. [01] 09151-70100 GASKET, COVER 22847-2380A
029. [01] 09151-70130 GASKET, COVER
030. [01] 09011-90160 GASKET, PUMP BODY 22847-2510A
031. [01] 09154-30040 PLUG, SCREW
032. [01] 09169-02774 HOUSING SUB-ASSY, 22370-2340A
032-001. [01] 09169-10051 HOUSING, FULL LOAD 22370-2240A
032-002. [01] 09148-70230 BLOCK, SLIDING
032-003. [01] 09156-30060 SHAFT, LEVER SUPPO 22338-1090A
032-004. [01] 09031-70270 PLUG, SCREW 22845-1480A
032-005. [01] 09091-90321 ADAPTER 22385-1670A
032-006. [01] 09098-30300 PIN, CONNECTING 22455-1230A
032-007. [01] 09091-90740 ADAPTER
032-008. [01] 09083-50140 COLLAR 22332-1980A
032-009. [01] 09152-12491 CAM, FULL STOP 22369-3270A
032-010. [01] 09095-30181 BUSHING 22322-1701A
032-011. [01] 09091-82890 SPRING, MECHANICAL 22321-3930A
032-012. [01] 09091-82880 SPRING, MECHANICAL 22321-3940A
032-013. [01] 09105-10651 PLATE, COVER 22371-1240A
032-014. [01] 94914-04200 O-RING 22817-1320A
032-014. [01] 09169-40230 GASKET 22847-2690A
032-015. [01] 94914-02030 O-RING 22817-1310A
032-015. [01] 09169-40220 GASKET 22847-2590A
032-016. [01] 09091-82110 SPRING, MECHANICAL 22411-1800A
032-017. [01] 19260-00901 COMPENSATOR SUB-AS 22340-1220A
032-018. [02] 90160-06051 NUT, HEXAGON 22825-1480A
032-019. [01] 90170-06361 NUT, HEXAGON 92100-6040A
032-020. [01] 09103-10220 NUT, CAP 22342-1650A
032-021. [02] 94904-81460 BOLT, WASHER HEAD 22815-3490A
032-022. [02] 09024-80010 WASHER, DRAIN SCRE 22847-1730A
032-023. [01] 09152-40390 SCREW, STOPPER 22395-1480A
032-024. [03] 91418-06161 BOLT, W/WASHER 22815-1380A
032-024. [04] 91418-06161 BOLT, W/WASHER 22815-1380A
032-025. [01] 09089-40020 E-RING 22873-1390A
032-026. [1C] 94901-32370 WASHER, PLATE, SK 22885-1930A
032-026. [1C] 94901-35020 WASHER, PLATE, SK 22885-1440A
032-026. [1C] 94901-35030 WASHER, PLATE, SK 22885-1450A
032-027. [01] 90801-20260 O-RING 22847-2140A
032-028. [01] 94904-74620 BOLT, W/WASHER 22815-2920A
032-028. [02] 94904-74620 BOLT, W/WASHER 22815-2920A
032-029. [01] 09116-90080 NUT 22821-2820A
033. [01] 09115-90670 ARM SUB-ASSY 22307-2650A
034. [01] 09104-20590 SPRING, RETURN 22341-1700A
035. [01] 09087-80280 PLATE 22343-5550A
037. [02] 09057-30160 BOLT, DIAPHRAGM CO
043. [04] 91418-06161 BOLT, W/WASHER 22815-1380A
043. [01] 91418-06161 BOLT, W/WASHER 22815-1380A
045. [01] 09105-00630 PLATE SUB-ASSY, CO 22341-4830A
045. [01] 09069-70231 BRACKET SUB-ASSY,
045-001. [01] 09105-00630 PLATE SUB-ASSY, CO 22341-4830A
045-002. [01] 09647-20772 ACTUATOR SET, IDLE 22470-1191A
045-002. [01] 09647-20771 ACTUATOR SET, IDLE 22470-1191A
045-02A. [01] 09647-20642 ACTUATOR SET, IDLE 22470-1210A
045-02A. [01] 09647-20643 ACTUATOR SET, IDLE 22470-1210A
045-02B. [01] 09007-30150 NIPPLE, ELBOW 97391-4106A
045-02B. [01] 09007-30190 NIPPLE, ELBOW 97391-4109A
045-02C. [01] 94901-81500 WASHER, COPPER PLA 22847-1120A
045-02C. [01] 09025-10010 WASHER, INJECTION 22865-1290A
045-02D. [01] 09092-30100 NUT, ADAPTER LOCK 22825-2340A
045-02E. [01] 09007-80180 COVER 22323-1370A
046. [03] 91418-06141 BOLT, W/WASHER 22815-1480A
047. [01] 09069-70100 BRACKET SUB-ASSY,
048. [01] 09115-90660 ARM SUB-ASSY 22307-2660A
049. [01] 09109-82591 STOPPER 22395-1930A
051. [01] 94914-00130 O-RING 22817-1440A
053. [01] 09104-20690 SPRING, RETURN 22341-1750A
056. [01] 09140-30460 WASHER, LOCK 22877-1990A
057. [01] 09140-30420 WASHER, LOCK 22877-1880A
058. [01] 94933-06540 TUBE, RUBBER 22385-1800A
059. [01] 94914-02190 O-RING 22847-1540A
060. [01] 09169-40160 GASKET 22847-2400A
061. [1C] 09141-10450 SHAFT, SLIDING WEI 22318-1450A
061. [1C] 09141-10380 SHAFT, SLIDING WEI
061. [1C] 09141-10370 SHAFT, SLIDING WEI
061. [1C] 09141-10360 SHAFT, SLIDING WEI
061. [1C] 09141-10350 SHAFT, SLIDING WEI
061. [1C] 09141-10340 SHAFT, SLIDING WEI
061. [1C] 09141-10330 SHAFT, SLIDING WEI
061. [1C] 09141-10320 SHAFT, SLIDING WEI
062. [04] 91418-06351 BOLT, W/WASHER 22815-1920A
062. [05] 91418-06351 BOLT, W/WASHER 22815-1920A
063. [1C] 94901-31980 WASHER, PLATE, SK 22885-3450A
063. [1C] 94901-31970 WASHER, PLATE, SK 22885-3440A
063. [1C] 94901-31960 WASHER, PLATE, SK 22885-3430A
064. [1C] 09140-30300 WASHER, LOCK 22877-1360A
064. [1C] 09140-30310 WASHER, LOCK 22877-1370A
064. [1C] 09140-30320 WASHER, LOCK 22877-1380A
064. [1C] 09140-30330 WASHER, LOCK 22877-1390A
066. [01] 94901-16220 WASHER, STEEL PLAT 22877-1320A
069. [02] 09104-11061 SPRING SUB-ASSY, R 22341-4800A
071. [04] 94904-81460 BOLT, WASHER HEAD
075. [01] 94904-74620 BOLT, W/WASHER 22815-2920A
077. [2C] 09140-30290 WASHER, LOCK 22877-1460A
077. [2C] 09140-30280 WASHER, LOCK 22877-1450A
077. [2C] 09140-30270 WASHER, LOCK 22877-1440A
077. [2C] 09140-30260 WASHER, LOCK 22877-1430A
077. [2C] 09140-30250 WASHER, LOCK 22877-1420A
077. [2C] 09140-30240 WASHER, LOCK 22877-1410A
077. [2C] 09140-30230 WASHER, LOCK 22877-1400A
081. [01] 09072-10150 PLATE 22343-3180A
082. [01] 09069-00780 BRACKET SUB-ASSY, 22343-6760A
083. [01] 94918-00060 SCREW, HOLLOW 22835-1110A
085. [02] 94901-02470 WASHER 22847-1900A
089. [01] 09647-20770 ACTUATOR SET, IDLE 24470-1190A
089-001. [01] 09647-20641 ACTUATOR SET, IDLE 22470-1210A
089-002. [01] 09007-30150 NIPPLE, ELBOW 97391-4106A
089-003. [01] 09025-10010 WASHER, INJECTION 22865-1290A
089-004. [01] 09092-30100 NUT, ADAPTER LOCK 22825-2340A
089-005. [01] 09007-80180 COVER 22323-1370A

Include in #3:

09130-05844 as GOVERNOR ASSY, MEC

Cross reference number



Part num Firm num Firm Name
09130-05844  22310-5910  GOVERNOR ASSY, MEC




Information:

Overcooling
Possible Causes/Corrections Long Idle PeriodsWhen the engine is running with no load, only a small quantity of fuel is burnt and engine heat is removed too fast. Very Light LoadVery light loads, and a very slow speed or downhill travel can cause overcooling because of the low heat input of the engine. The installation of shutters helps to correct this condition. Defective Water Temperature RegulatorsA regulator that is "stuck" open (will not move to the closed position) will cause overcooling. A thermostat that is stuck between the open and closed positions, or only opens part of the way, can cause overcooling when the truck has a light load. Also, coolant leaks around the thermostat, such as vent lines, can cause overcooling.
