09130-05082 GOVERNOR ASSY, MEC Denso Cross




Information governor assy, mec

09130-05082 GOVERNOR ASSY, MEC
Rating:
34
Buy GOVERNOR ASSY, MEC 09130-05082 genuine, new aftermarket engine parts with delivery

Scheme ###:

GOVERNOR ASSY, MEC
000. [01] 09130-05082 GOVERNOR ASSY, MEC ME736508
001. [01] 09131-00050 HOUSING SUB-ASSY, ME703107
001-001. [01] 09101-60020 BUSHING, BEARING ME702636
002. [01] 09145-00881 COVER ASSY, GOVERN ME736063
003. [01] 09133-01442 FLYWEIGHT ASSY ME736641
003-001. [01] 09137-00042 FLYWEIGHT SUB-ASSY ME736515
003-005. [01] 09134-00031 BUSHING ASSY, CAMS ME702587
003-006. [02] 09137-70343 SEAT, GOVERNOR SPR ME703119
003-007. [02] 09136-30010 SEAT, GOVERNOR SPR ME702138
003-008. [02] 09139-30091 GUIDE, SPRING ME702142
003-009. [02] 09091-81710 SPRING, MECHANICAL ME702137
003-010. [01] 09138-91311 SPRING, IDLING ME736642
003-011. [02] 09139-50020 NUT, ADJUSTING ME702143
003-011. [02] 09139-50050 NUT, ADJUSTING ME728670
003-012. [01] 09140-50080 BUSHING, GUIDE ME703779
003-013. [01] 09140-10040 BOLT, BELLCRANK ME702144
003-013. [01] 09140-10061 BOLT, BELLCRANK ME743665
003-014. [02] 94904-78260 BOLT, W/WASHER ME736916
003-014. [02] 91418-06161 BOLT, W/WASHER ME702149
003-015. [06] 09133-70150 DAMPER, FLYWEIGHT ME703171
003-016. [02] 09138-91320 SPRING, IDLING ME736577
003-017. [02] 09139-10530 SPRING, SPEED CONT ME728800
003-018. [02] 09089-40101 E-RING ME743666
003-018. [02] 90160-06051 NUT, HEXAGON ME702588
003-019. [01] 09140-30010 WASHER, LOCK ME702145
003-020. [2C] 09140-30190 WASHER, LOCK ME702147
003-020. [2C] 09140-30200 WASHER, LOCK ME703124
003-020. [2C] 09140-30410 WASHER, LOCK ME703123
003-020. [2C] 09140-30700 WASHER, LOCK ME728578
003-020. [2C] 09140-30710 WASHER, LOCK ME728579
003-021. [2C] 09140-30400 WASHER, LOCK ME703125
003-021. [2C] 09140-30180 WASHER, LOCK ME702263
003-021. [2C] 09140-30170 WASHER, LOCK ME702262
003-021. [2C] 09140-30160 WASHER, LOCK ME702146
003-022. [01] 94901-33970 WASHER, PLATE, SK ME702150
003-022. [02] 09140-30800 WASHER, LOCK ME743667
003-023. [01] 09133-40040 NUT, ROUND ME702585
003-024. [1C] 09133-10200 SHIM ME703159
003-024. [1C] 09133-10210 SHIM ME703160
003-024. [1C] 09133-10220 SHIM ME703161
003-024. [1C] 09133-10230 SHIM ME703148
003-024. [1C] 09133-10240 SHIM ME703149
003-024. [1C] 09133-10250 SHIM ME703150
003-024. [1C] 09133-10190 SHIM ME703158
003-024. [1C] 09133-10180 SHIM ME703157
003-024. [1C] 09133-10170 SHIM ME703156
003-024. [1C] 09133-10110 SHIM ME702584
003-024. [1C] 09133-10120 SHIM ME703151
003-024. [1C] 09133-10130 SHIM ME703152
003-024. [1C] 09133-10140 SHIM ME703153
003-024. [1C] 09133-10150 SHIM ME703154
003-024. [1C] 09133-10160 SHIM ME703155
003-025. [01] 09138-90910 SPRING, IDLING ME703780
006. [01] 09142-60081 SLIDER ME702154
007. [01] 09143-00110 LEVER ASSY, FLOATI ME702156
007-001. [01] 09143-60212 LEVER SUB-ASSY, FL ME702161
007-002. [01] 09169-50041 STOPPER SUB-ASSY, ME702162
007-003. [01] 09094-00410 LEVER SUB-ASSY, CO ME702158
007-004. [01] 09104-20580 SPRING, RETURN ME702159
007-005. [01] 09104-20610 SPRING, RETURN ME702160
007-006. [02] 09089-40020 E-RING ME702639
007-007. [2C] 94901-35080 WASHER, PLATE, SK ME728577
007-007. [2C] 94901-35090 WASHER, PLATE, SK ME703128
007-007. [2C] 94901-33960 WASHER, PLATE, SK ME702190
007-007. [2C] 94901-32370 WASHER, PLATE, SK ME703127
007-007. [2C] 94901-31390 WASHER, PLATE, SK ME703126
008. [01] 09098-00401 SHACKLE SUB-ASSY ME703025
009. [1C] 09148-00220 ARM ASSY, GUIDE ME736066
009. [1C] 09148-00210 ARM ASSY, GUIDE ME736065
009. [1C] 09148-00200 ARM ASSY, GUIDE ME736064
009-001. [01] 19089-00780 OVER-HAUL KIT, GOV ME736492
011. [01] 94915-02522 SEAL, OIL ME728021
012. [01] 09101-70051 PLATE, CAM ME702540
013. [01] 09104-20600 SPRING, RETURN ME702121
014. [03] 09089-40020 E-RING ME702639
015. [02] 09156-00031 LEVER SUB-ASSY, SU ME703162
016. [01] 09156-30050 SHAFT, LEVER SUPPO ME702173
017. [01] 09107-04130 LEVER SUB-ASSY, AD ME736070
018. [01] 09129-10160 LEVER SET ME736071
019. [02] 09116-70110 PLUG, SCREW ME702131
020. [01] 09107-04320 LEVER SUB-ASSY, AD ME736493
021. [01] 94913-00030 KEY, WOODRUFF ME702205
022. [01] 09082-10254 STOPPER ME702106
023. [01] 09116-90024 NUT ME702132
024. [02] 91418-06201 BOLT, W/WASHER ME702041
026. [01] 94904-03840 BOLT, HEXAGON ME702201
027. [01] 94919-26770 COLLAR, STEEL ME736130
028. [03] 94904-71760 BOLT, W/WASHER ME702581
029. [01] 09151-70080 GASKET, COVER ME728999
030. [01] 09082-30460 GASKET ME736516
031. [01] 09154-30031 PLUG, SCREW ME702171
032. [01] 09169-02432 HOUSING SUB-ASSY, ME736643
032-001. [01] 09169-10041 HOUSING, FULL LOAD ME702544
032-002. [01] 09148-70180 BLOCK, SLIDING ME743337
032-003. [01] 09156-30040 SHAFT, LEVER SUPPO ME702543
032-004. [01] 09031-70270 PLUG, SCREW ME728357
032-005. [01] 09091-90670 ADAPTER ME736541
032-005. [01] 09091-90710 ADAPTER ME736689
032-006. [01] 09095-30181 BUSHING ME702183
032-007. [01] 09091-82860 SPRING, MECHANICAL ME736542
032-007. [01] 09091-82880 SPRING, MECHANICAL ME736691
032-008. [01] 09091-81640 SPRING, MECHANICAL ME702179
032-009. [01] 09152-12135 CAM, FULL STOP ME736644
032-010. [01] 09098-30300 PIN, CONNECTING ME702184
032-011. [01] 09105-11140 PLATE, COVER ME736544
032-012. [01] 09152-40440 SCREW, STOPPER ME703966
032-013. [01] 09116-90080 NUT ME703967
032-014. [01] 09103-10220 NUT, CAP ME703968
032-015. [02] 09024-80010 WASHER, DRAIN SCRE ME702175
032-016. [01] 94904-74620 BOLT, W/WASHER ME728101
032-016. [01] 94904-78060 BOLT, W/WASHER ME736692
032-017. [02] 90160-06051 NUT, HEXAGON ME702588
032-018. [01] 90170-06361 NUT, HEXAGON ME702591
032-019. [01] 94914-02030 O-RING ME702853
032-020. [01] 94914-06360 O-RING ME728427
032-021. [01] 09091-90680 ADAPTER ME736545
032-021. [01] 09091-90700 ADAPTER ME743229
032-022. [01] 09091-82890 SPRING, MECHANICAL ME736693
032-022. [01] 09091-82870 SPRING, MECHANICAL ME736547
032-023. [01] 09089-40020 E-RING ME702639
032-024. [1C] 94901-32370 WASHER, PLATE, SK ME703127
032-024. [1C] 94901-35020 WASHER, PLATE, SK ME702628
032-024. [1C] 94901-35030 WASHER, PLATE, SK ME702741
032-025. [01] 91418-06161 BOLT, W/WASHER ME702149
032-026. [02] 94904-81460 BOLT, WASHER HEAD ME743678
033. [01] 09115-90540 ARM SUB-ASSY ME703739
034. [01] 09104-20590 SPRING, RETURN ME702120
035. [01] 09087-80060 PLATE ME703478
037. [02] 09057-30150 BOLT, DIAPHRAGM CO ME703705
042. [01] 94933-06540 TUBE, RUBBER ME703992
043. [05] 91418-06161 BOLT, W/WASHER ME702149
044. [01] 90200-06241 WASHER, PLATE ME703805
045. [01] 09105-10540 PLATE, COVER ME703135
046. [01] 91418-06141 BOLT, W/WASHER ME702592
047. [01] 91418-06251 BOLT, W/WASHER ME703889
048. [01] 09115-90141 ARM SUB-ASSY ME703136
049. [01] 09109-01431 LEVER SUB-ASSY, ST ME736546
049. [01] 09109-01740 LEVER SUB-ASSY, ST
050. [02] 90160-06051 NUT, HEXAGON ME702588
051. [01] 94914-00130 O-RING ME702207
053. [01] 09104-20010 SPRING, RETURN ME703585
054. [01] 09104-30010 COVER, SPRING ME702122
056. [01] 09140-30460 WASHER, LOCK ME703741
057. [01] 09140-30420 WASHER, LOCK ME702152
058. [01] 09072-10150 PLATE ME703720
059. [01] 94914-02190 O-RING ME702208
060. [01] 09169-40170 GASKET ME736002
061. [1C] 09141-10460 SHAFT, SLIDING WEI ME736003
061. [1C] 09141-10240 SHAFT, SLIDING WEI ME703143
061. [1C] 09141-10230 SHAFT, SLIDING WEI ME703142
061. [1C] 09141-10220 SHAFT, SLIDING WEI ME703141
061. [1C] 09141-10210 SHAFT, SLIDING WEI ME703140
061. [1C] 09141-10200 SHAFT, SLIDING WEI ME703139
061. [1C] 09141-10190 SHAFT, SLIDING WEI ME703138
061. [1C] 09141-10180 SHAFT, SLIDING WEI ME702153
061. [1C] 09141-10470 SHAFT, SLIDING WEI ME736004
062. [03] 91418-06351 BOLT, W/WASHER ME702594
063. [1C] 94901-31960 WASHER, PLATE, SK ME702866
063. [1C] 94901-31970 WASHER, PLATE, SK ME702867
063. [1C] 94901-31980 WASHER, PLATE, SK ME023379
064. [1C] 09140-30330 WASHER, LOCK ME703111
064. [1C] 09140-30320 WASHER, LOCK ME703110
064. [1C] 09140-30310 WASHER, LOCK ME703109
064. [1C] 09140-30300 WASHER, LOCK ME702151
066. [01] 94901-16220 WASHER, STEEL PLAT ME703144
068. [01] 09069-70140 BRACKET SUB-ASSY, ME736548
069. [02] 09104-10910 SPRING SUB-ASSY, R ME728997
070. [01] 09104-20801 SPRING, RETURN ME703184
071. [01] 94904-72701 BOLT, W/WASHER ME702204
077. [2C] 09140-30290 WASHER, LOCK ME703117
077. [2C] 09140-30280 WASHER, LOCK ME703116
077. [2C] 09140-30270 WASHER, LOCK ME703115
077. [2C] 09140-30260 WASHER, LOCK ME703114
077. [2C] 09140-30250 WASHER, LOCK ME703113
077. [2C] 09140-30240 WASHER, LOCK ME703112
077. [2C] 09140-30230 WASHER, LOCK ME702589
078. [01] 09069-10810 BRACKET, STOP WIRE ME702105
080. [01] 09266-40020 SCREW, LEVER STOP ME702654

Include in #3:

09130-05082 as GOVERNOR ASSY, MEC

Cross reference number



Part num Firm num Firm Name
09130-05082  ME736508  GOVERNOR ASSY, MEC




Information:

start by:a) remove oil panb) remove crankshaft pulley1. Remove nuts (2) and tachometer drive cover (1). 2. Remove bolts (3) and front support (4). 3. Loosen clamp (5) and disconnect hose (6) from the timing gear cover. 4. Remove clips (8) and then disconnect three lines (7). 5. Remove clamp (9) from the water sleeve.6. Install tool (A) on the water sleeve and then push water sleeve (10) into the front cover. 7. Remove two bolts (11), connector (12) and the gasket behind it. 8. Remove bolts (13), elbow (14) and the gasket behind it. 9. Remove bolt (15) and then disconnect clamp (16) that holds the oil pump sump tube. 10. Install tooling (B) in the front cover and then fasten a hoist. Remove all the bolts that hold timing gear cover to the cylinder block. Remove the cover (17) and oil pump. The weight of the timing gear cover and oil pump is 62 kg (136 lb.).
Be extra careful not to cause damage to the crankshaft front seal during removal and installation of the timing gear cover.
Install Timing Gear Cover And Oil Pump
1. Clean the contact surfaces of the cylinder block and timing gear cover. Install the timing gear cover gasket on the cylinder block. Make sure the water sleeves are installed in the timing gear cover. Put oil on the seals on the water sleeves. 2. Install tooling (A) on timing gear cover (1).3. Put the cover in position and make an alignment of the dowels and their respective holes. Install the bolts that hold cover (1) to the cylinder block. 4. Connect clamp (3) that holds the oil pump sump tube. Install bolt (2). 5. Install gasket and elbow (4) on the timing gear cover with the bolts (5) that hold it.6. Install gasket and connector (7) in the cover and install the bolts (6) that hold it. 7. Install tool (B) on water sleeve (8), then push water sleeve into the cylinder block. 8. Install clamps (9) on the water sleeve. 9. Connect three lines (10) and install the clips (11) that hold them. 10. Install hose (13) on timing gear cover and install clamp (12). 11. Put engine support (16) in position and install the bolts (17) that hold it. 12. Put tachometer cover (15) in position and install the nuts (14) that hold it. end by:a) install crankshaft pulleyb) install oil pan
