09130-00802 GOVERNOR ASSY, MEC Denso Cross




Information governor assy, mec

09130-00802 GOVERNOR ASSY, MEC
Rating:
72
Buy GOVERNOR ASSY, MEC 09130-00802 genuine, new aftermarket engine parts with delivery

Scheme ###:

000. [01] 09130-00800 GOVERNOR ASSY, MEC 22310-2332
000. [01] 09130-00801 GOVERNOR ASSY, MEC 22310-2332
000. [01] 09130-00802 GOVERNOR ASSY, MEC 22310-2332
001. [01] 09131-10142 HOUSING, GOVERNOR 22391-1382A
002. [01] 09011-90030 GASKET, PUMP BODY 22352-1130A
002. [01] 09011-90140 GASKET, PUMP BODY
003. [ C] 94901-13280 WASHER, STEEL PLAT 22863-1350A
003. [ C] 94901-13270 WASHER, STEEL PLAT 22863-1340A
003. [ C] 94901-13260 WASHER, STEEL PLAT 22863-1330A
003. [ C] 94901-13250 WASHER, STEEL PLAT 22863-1320A
003. [ C] 94901-13240 WASHER, STEEL PLAT 22863-1310A
004. [01] 09116-70050 PLUG, SCREW 22845-1030A
005. [01] 09133-00481 FLYWEIGHT ASSY 22360-1291A
005-001. [01] 09135-00021 HOLDER SUB-ASSY, F 22314-1121A
005-001. [01] 09135-00022 HOLDER SUB-ASSY, F 22314-1121A
005-002. [02] 09137-30040 FLYWEIGHT 22344-1090A
005-003. [04] 09137-50020 PIN, FLYWEIGHT 22358-1300A
005-004. [04] 94908-00030 PIN, GROOVED 22358-1360A
005-005. [02] 09137-70100 SEAT, GOVERNOR SPR 22351-1240A
005-006. [02] 09136-10060 BELLCRANK 22324-1090A
005-007. [02] 09136-10050 BELLCRANK 22324-1080A
005-008. [02] 09139-70010 PIN, RETAINING 22358-1180A
005-009. [02] 09139-90021 SHAFT, BELLCRANK 22334-1020A
005-010. [01] 09140-10050 BOLT, BELLCRANK 22815-2430A
005-011. [01] 09140-30010 WASHER, LOCK 22863-1190A
005-012. [02] 90160-06051 NUT, HEXAGON 22825-1480A
005-013. [ C] 09138-90510 SPRING, IDLING 22411-1630A
005-013. [ C] 09138-90500 SPRING, IDLING 22411-1620A
005-014. [ C] 09139-20640 SPRING, SPEED CONT 22321-2020A
005-014. [ C] 09139-20650 SPRING, SPEED CONT 22321-2030A
005-015. [02] 09139-10290 SPRING, SPEED CONT 22321-1710A
005-016. [02] 09139-30050 GUIDE, SPRING 22351-1710A
005-017. [02] 09139-50010 NUT, ADJUSTING 22342-1050A
005-018. [01] 09134-00012 BUSHING ASSY, CAMS 22322-1630A
005-019. [04] 09133-70030 DAMPER, FLYWEIGHT 22314-1010A
005-021. [ C] 09133-10010 SHIM 22321-1510A
005-021. [ C] 09133-10100 SHIM 22885-1060A
005-021. [ C] 09133-10090 SHIM 22885-1050A
005-021. [ C] 09133-10070 SHIM 22881-2630A
005-021. [ C] 09133-10060 SHIM 22881-2620A
005-021. [ C] 09133-10050 SHIM 22881-2610A
005-021. [ C] 09133-10040 SHIM 22881-2600A
005-021. [ C] 09133-10030 SHIM 22881-2590A
005-021. [ C] 09133-10020 SHIM 22881-2580A
005-022. [01] 09133-40080 NUT, ROUND
005-022. [01] 09133-40090 NUT, ROUND 22825-1940A
005-023. [02] 09139-30080 GUIDE, SPRING 22385-1420A
005-024. [02] 09168-40061 SPRING, ADAPTER 22414-1170A
005-025. [02] 09168-50120 WASHER, ADJUSTING 22877-1960A
005-026. [02] 09168-60031 CAP, ADAPTER SPRIN 22342-1350A
005-028. [ C] 94901-30400 WASHER, PLATE, SK 22885-3840A
005-028. [ C] 94901-30410 WASHER, PLATE, SK 6 076 1304 70
005-029. [02] 09139-10420 SPRING, SPEED CONT 22321-2140A
006. [01] 94904-71190 BOLT, W/WASHER 22815-1230A
007. [04] 91518-06161 BOLT, W/WASHER 22815-1310A
008. [01] 09140-50010 BUSHING, GUIDE 22314-1060A
008. [01] 09140-50020 BUSHING, GUIDE 6 053 1358 20
009. [01] 94913-00050 KEY, WOODRUFF 22895-1020A
011. [02] 94904-72700 BOLT, W/WASHER 22815-2030A
012. [01] 09140-90010 WIRE 22333-1060A
013. [ C] 09141-10140 SHAFT, SLIDING WEI 22318-1080A
013. [ C] 09141-10130 SHAFT, SLIDING WEI 22318-1070A
013. [ C] 09141-10120 SHAFT, SLIDING WEI 22318-1060A
014. [02] 09144-30010 PIN, LINK FORK 22455-1100A
015. [01] 09057-30032 BOLT, DIAPHRAGM CO 22322-1170A
016. [01] 90258-05001 WASHER, SPRING 22873-1380A
017. [03] 90400-16101 PIN, SPLIT 22456-1030A
018. [01] 91160-05041 NUT, HEXAGON 22456-1020A
019. [ C] 94901-33990 WASHER, PLATE, SK 22885-1480A
019. [ C] 94901-33980 WASHER, PLATE, SK 22885-1470A
022. [01] 09151-70021 GASKET, COVER 22847-1410A
023. [01] 09145-00080 COVER ASSY, GOVERN 22380-1130A
026. [01] 09103-60020 CUP, SPRING 22307-1460A
027. [01] 09103-90020 SEAT, SPRING 22307-1440A
028. [01] 09103-80020 SPRING, B 22307-1450A
029. [01] 09148-20020 ARM, GUIDE 22307-1470A
030. [01] 09149-00010 BLOCK SUB-ASSY, SL 22307-1430A
031. [01] 94908-31040 PIN 22358-1310A
032. [02] 94915-00380 SEAL, OIL 22823-1230A
033. [01] 09149-10040 SHAFT, ADJUSTING L 22339-1050A
034. [01] 09151-00140 LEVER ASSY, ADJUST 22319-1350A
035. [01] 09151-00070 LEVER ASSY, ADJUST 22319-1470A
036. [02] 94913-00030 KEY, WOODRUFF 22891-1060A
037. [01] 09152-40270 SCREW, STOPPER 22395-1300A
038. [02] 94901-90680 WASHER, FIBER 22843-1390A
039. [02] 09154-30020 PLUG, SCREW 22393-1070A
040. [01] 09091-10080 SCREW, ADPTER 22396-1150A
041. [01] 09091-90150 ADAPTER 22385-1140A
042. [01] 09006-30100 SPRING, IDLE 22412-1110A
043. [01] 09089-40010 E-RING 22863-1810A
044. [01] 09003-20040 CAP 22342-1110A
045. [02] 94901-80350 WASHER, COPPER PLA 22847-1950A
046. [01] 94805-30100 NUT, HEXAGON, W/HO 22885-3830A
048. [01] 09152-40170 SCREW, STOPPER 22395-1310A
049. [01] 09143-00090 LEVER ASSY, FLOATI 22041-1090A
050. [01] 09142-60070 SLIDER 22349-1020A
051. [01] 09144-00080 LINK ASSY, FORK 22317-1200A
052. [01] 09158-50011 SEAT 22332-1330A
053. [02] 09133-40030 NUT, ROUND 22825-1120A
054. [01] 09140-30220 WASHER, LOCK 22877-1150A
055. [01] 09157-80020 SPRING, RETURN 22341-1520
056. [01] 09169-50030 STOPPER SUB-ASSY, 22396-1130A
057. [01] 94917-10800 SPRING, TENSION CO 22341-1510A
058. [01] 94900-30940 SCREW, STOP 22396-1010A
059. [01] 94905-30051 NUT, HEXAGON, W/ H 22821-1540A
060. [02] 94901-81020 WASHER, COPPER PLA 22867-1500A
061. [01] 09103-10041 NUT, CAP 22342-1150A
061. [01] 09103-10200 NUT, CAP 22342-1500A
062. [01] 09158-00021 LEVER ASSY, MAXIMU 22407-1040A
062-001. [02] 09158-30011 BOLT, CONNECTING 22815-1680A
062-002. [02] 09217-60010 ROLLER, FEED PUMP 22569-1110A
062-003. [02] 09089-40020 E-RING 22873-1390A
063. [01] 09156-30010 SHAFT, LEVER SUPPO 22338-1010A
064. [01] 09156-30020 SHAFT, LEVER SUPPO 22338-1020A
065. [01] 09099-10010 PLUG, SCREW 22845-1210A
066. [02] 09156-00010 LEVER SUB-ASSY, SU 22045-1010A
067. [02] 09116-70110 PLUG, SCREW 22845-1250A
068. [01] 09105-10310 PLATE, COVER 22386-1700A
069. [01] 09105-70050 GASKET, COVER PLAT 22847-1350A
070. [03] 94901-31420 WASHER, PLATE, SK 22867-1040A
071. [01] 09116-90070 NUT 22342-1510A
071. [01] 09634-20010 NUT, LOCK 22821-1530A
072. [01] 09168-70080 SPACER 22385-1300A
074. [01] 09099-30140 SPRING, START 22331-1130A
075. [01] 09087-80050 PLATE 22392-1050A
076. [01] 09101-60270 BUSHING, BEARING 22322-1450A
077. [01] 94914-00130 O-RING 22817-1440A
078. [01] 09115-90120 ARM SUB-ASSY 22348-1230A
078. [01] 09115-90260 ARM SUB-ASSY 22348-1230A
079. [01] 94901-31970 WASHER, PLATE, SK 22885-3440A
084. [01] 09104-10160 SPRING SUB-ASSY, R 22341-2400A
085. [01] 09109-00760 LEVER SUB-ASSY, ST 22348-1630A
086. [01] 09152-40180 SCREW, STOPPER 22395-1180A
087. [01] 90190-08051 NUT, HEXAGON 22825-1130A
088. [01] 90258-08001 WASHER, SPRING 22877-1720A
089. [01] 09097-30030 ARM, SPRING 22044-1090A
090. [02] 91410-08141 BOLT, W/WASHER 22815-2570A
091. [01] 94901-31980 WASHER, PLATE, SK 22885-3450A

Include in #3:

09130-00802 as GOVERNOR ASSY, MEC

Cross reference number



Part num Firm num Firm Name
09130-00802  22310-2332  GOVERNOR ASSY, MEC




Information:


Ether is poisonous and flammable. Keep ether cylinders out of the reach of unauthorized personnel.Breathing ether vapors or repeated contact of ether with skin can cause personal injury.Use ether only in well ventilated areas.Use ether with care to avoid fires.Do not smoke while changing ether cylinders.Do not store ether cylinders in the operator's compartment.Do not store ether cylinders in direct sunlight or at temperatures above 48°C (120°F).Discard ether cylinders properly. Do not puncture or burn ether cylinders.
The Testing And Adjusting procedures use the wiring, components and connectors as shown in the Automatic Ether Injection System Schematic at the end of this module. For an accurate representation of the vehicle, see the respective Electrical System Schematic module.The description "with MPPS" and "without MPPS" are used throughout this manual: * "with MPPS" describes vehicles with the multi-point pressure sensing (MPPS) function. "with MPPS" vehicles use the 3E3778 Ether Injection Control with an engine oil pressure sensor.* "without MPPS" describes vehicles without the multi-point pressure sensing (MPPS) function. "without MPPS" vehicles use either the earlier 9X5303 Ether Injection Control or the 3E3778 without an engine oil pressure sensor.
Part No. Location Of Ether Injection ControlThe Part No., as described above, identifies the "with MPPS" or "without MPPS" capabilities. The part number and change level are stamped on the ether injection control.The 3E3778 Ether Injection Control replaces the 9X5303 Ether Injection Control. 3E3778 is capable of operating "with MPPS" or "without MPPS". The harness code determines whether the MPPS function is enabled or not.Troubleshooting
Inspect all component and harness connections before any component is replaced. If these connections are not tight they can be the cause of electrical problems, either permanent or intermittent (come and go). Make sure the connections are tight before other tests are made.Failure of an electrical component can cause or be caused by the failure of one or more other components. Always find and correct the cause of electrical component failure before making a replacement of the component.The 6V7070 Digital Multimeter or equivalent Caterpillar multimeter should be used for making continuity checks or voltage measurements. For instruction on use of the 6V7070, see Special Instructions, Form No. SEHS7734. The Testing And Adjusting procedures use the wiring, components and connectors as shown in the Automatic Ether Injection System Schematic at the end of this module. For an accurate representation of the vehicle, see the respective Electrical System Schematic module.System Diagnostics
The Automatic Ether Injection System provides a number of built-in diagnostic capabilities. These are designed to make service and maintenance of the system as simple as possible. The Troubleshooting section details the use of the system diagnostics.The ether injection control determines when an ether cylinder needs replaced and determines the source of most electrical faults in the ether injection system. The conditions that correspond to the operation of the warning lamps and warning alarm are listed in the Warning Indicator Problems section. Electrical system faults that are
