Information bellows assy, pneu
Rating:
Scheme ###:
| 000. | [01] | 09071-00700 | BELLOWS ASSY, PNEU | |
| 001. | [01] | 09644-00770 | COVER SUB-ASSY, GO | |
| 002. | [01] | 09071-60120 | COVER | |
| 003. | [01] | 09071-10050 | BELLOWS SUB-ASSY, | |
| 004. | [01] | 09646-90880 | R0D SUB-ASSY, PUSH | |
| 004. | [01] | 09646-90580 | R0D SUB-ASSY, PUSH | |
| 005. | [01] | 09611-80080 | BUSHING, GUIDE | |
| 006. | [01] | 09611-80020 | BUSHING, GUIDE | |
| 007. | [01] | 09645-50090 | PIN, LEVER CONECTI | |
| 008. | [01] | 09625-40021 | NUT, GOVERNOR SHAF | |
| 009. | [01] | 09604-90230 | O-RING | |
| 010. | [01] | 94901-81680 | WASHER, COPPER PLA | |
| 011. | [01] | 09629-50680 | LEVER SUB-ASSY, CO | |
| 012. | [01] | 09627-20040 | PIN, LEVER SUPPORT | |
| 013. | [02] | 09626-90032 | BOLT, GOVERNOR LIN | |
| 014. | [02] | 09642-60110 | GASKET, DELIVERY V | |
| 015. | [01] | 09031-70240 | PLUG, SCREW | |
| 016. | [01] | 09642-60120 | GASKET, DELIVERY V | |
| 017. | [01] | 94905-04070 | NUT, HEXAGON | |
| 018. | [01] | 09646-60110 | SPRING | |
| 019. | [01] | 09646-80020 | CAP RUBBER | |
| 020. | [04] | 09644-90130 | BOLT, SOCKET | 8-97161960-0 |
| 021. | [01] | 94914-03610 | O-RING | |
| 022. | [01] | 09646-80140 | CAP RUBBER | |
| 023. | [1C] | 09621-70140 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70080 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70070 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70060 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70050 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70040 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70030 | WASHER, TIMER ADJU | |
| 023. | [1C] | 09621-70020 | WASHER, TIMER ADJU | |
| 024. | [01] | 09646-60080 | SPRING |
