09071-00650 BELLOWS ASSY, PNEU Denso Cross

Information bellows assy, pneu

Price: query

Buy now
Add to cart Go to cart

Rating:

Buy BELLOWS ASSY, PNEU 09071-00650 genuine, new aftermarket engine parts with delivery

Scheme ###:

000.	[01]	09071-00650	BELLOWS ASSY, PNEU	22680-5D260
001.	[01]	09644-01200	COVER SUB-ASSY, GO	22703-5B121
002.	[01]	09071-60120	COVER	22682-54351
003.	[01]	09071-10050	BELLOWS SUB-ASSY,	22681-6A570
004.	[01]	09646-91070	R0D SUB-ASSY, PUSH	22301-5B760
004.	[1C]	09646-91070	R0D SUB-ASSY, PUSH	22301-5B760
004.	[1C]	09646-91040	R0D SUB-ASSY, PUSH	22301-5B680
004.	[1C]	09646-91081	R0D SUB-ASSY, PUSH	22301-5B840
004.	[1C]	09646-91050	R0D SUB-ASSY, PUSH	22301-5B720
005.	[01]	09611-80080	BUSHING, GUIDE	22348-64400
006.	[01]	09611-80020	BUSHING, GUIDE	22348-54121
007.	[01]	09645-50090	PIN, LEVER CONECTI	22338-54120
008.	[01]	09625-40021	NUT, GOVERNOR SHAF	22722-54120
009.	[01]	09604-90230	O-RING	22193-55031
010.	[01]	94901-81680	WASHER, COPPER PLA	90099-01473
011.	[01]	09629-50070	LEVER SUB-ASSY, CO	22308-54120
011.	[01]	09629-50670	LEVER SUB-ASSY, CO	22308-5B650
012.	[01]	09627-20040	PIN, LEVER SUPPORT	22526-54120
013.	[02]	09626-90032	BOLT, GOVERNOR LIN	22739-54120
014.	[02]	09642-60110	GASKET, DELIVERY V	22149-6D450
015.	[01]	09031-70240	PLUG, SCREW	22129-55110
016.	[01]	09642-60120	GASKET, DELIVERY V	22149-54800
017.	[01]	94905-04070	NUT, HEXAGON	90099-05156
018.	[01]	09646-60110	SPRING	22327-54800
019.	[01]	09646-80020	CAP RUBBER	22777-54120
020.	[04]	09644-90130	BOLT, SOCKET	22395-54263
021.	[01]	94914-03610	O-RING	90099-14057
022.	[01]	09646-80140	CAP RUBBER	22777-64410
023.	[1C]	09621-70140	WASHER, TIMER ADJU	22624-54806
023.	[1C]	09621-70080	WASHER, TIMER ADJU	22624-54805
023.	[1C]	09621-70070	WASHER, TIMER ADJU	22624-54804
023.	[1C]	09621-70060	WASHER, TIMER ADJU	22624-54803
023.	[1C]	09621-70050	WASHER, TIMER ADJU	22624-54800
023.	[1C]	09621-70040	WASHER, TIMER ADJU	22622-54010
023.	[1C]	09621-70030	WASHER, TIMER ADJU	22621-54010
023.	[1C]	09621-70020	WASHER, TIMER ADJU	22624-54010
024.	[01]	09646-60080	SPRING	22327-64400

Include in #3:

09071-00650 as BELLOWS ASSY, PNEU

Cross reference number

Part num	Firm num	Firm	Name
09071-00650	22680-5D26		BELLOWS ASSY, PNEU
22680-5D260		TOYOTA	BELLOWS ASSY, PNEU

Information:

(9) Depth of bore in head for valve seat insert:Intake ... 15.00 0.10 mm (.591 .004 in)Exhaust ... 14.10 0.10 mm (.555 .004 in) Inserts to be shrunk by reduced temperature before being placed in counterbore.(10) Diameter of valve seat insert for intake valve ... 46.025 0.013 mm (1.8120 .0005 in)Bore in head for valve seat insert for intake valve ... 45.950 0.025 mm (1.8091 .0010 in)Diameter of valve seat insert for exhaust valve ... 43.400 0.015 mm (1.7086 .0006 in)Bore in head for valve seat insert for exhaust valve ... 43.320 0.025 mm (1.7055 .0009 in)(11) Angle of face of intake valve seat insert ... 30 1/4 1/2°Angle of face of exhaust valve seat insert ... 44 3/4 1/2°(12) "Use again" thickness of valve lip:Exhaust valve ... 2.03 mm (.080 in)Intake valve ... 2.51 mm (.099 in)
