Information bellows assy, pneu
Rating:
Scheme ###:
| 000. | [01] | 09071-00230 | BELLOWS ASSY, PNEU | 22680-64400 |
| 001. | [01] | 09644-00641 | COVER SUB-ASSY, GO | 22703-54412 |
| 002. | [01] | 09071-60040 | COVER | 22682-64400 |
| 003. | [01] | 09071-10060 | BELLOWS SUB-ASSY, | 22681-64400 |
| 004. | [01] | 09646-90030 | R0D SUB-ASSY, PUSH | 22301-64680 |
| 005. | [01] | 09611-80080 | BUSHING, GUIDE | 22348-64400 |
| 006. | [01] | 09611-80020 | BUSHING, GUIDE | 22348-54121 |
| 007. | [01] | 09645-50090 | PIN, LEVER CONECTI | 22338-54120 |
| 008. | [01] | 09625-40021 | NUT, GOVERNOR SHAF | 22722-54120 |
| 009. | [01] | 09604-90230 | O-RING | 22193-55031 |
| 010. | [01] | 94901-81680 | WASHER, COPPER PLA | 90099-01473 |
| 011. | [01] | 09629-50070 | LEVER SUB-ASSY, CO | 22308-54120 |
| 011. | [01] | 09629-50670 | LEVER SUB-ASSY, CO | 22308-5B650 |
| 012. | [01] | 09627-20040 | PIN, LEVER SUPPORT | 22526-54120 |
| 013. | [02] | 09626-90032 | BOLT, GOVERNOR LIN | 22739-54120 |
| 014. | [02] | 09024-80010 | WASHER, DRAIN SCRE | 22378-76010 |
| 014. | [02] | 09642-60110 | GASKET, DELIVERY V | 22149-6D450 |
| 015. | [01] | 09031-70240 | PLUG, SCREW | 22129-55110 |
| 016. | [01] | 09024-10010 | WASHER, AIR BLEEDE | 22119-77020 |
| 016. | [01] | 09642-60120 | GASKET, DELIVERY V | 22149-54800 |
| 017. | [01] | 94905-04070 | NUT, HEXAGON | 90099-05156 |
| 018. | [01] | 09646-60050 | SPRING | 22327-54120 |
| 019. | [01] | 09646-80020 | CAP RUBBER | 22777-54120 |
| 020. | [04] | 09644-90130 | BOLT, SOCKET | 22395-54263 |
| 021. | [01] | 94914-03610 | O-RING | 90099-14057 |
| 022. | [01] | 09646-80140 | CAP RUBBER | 22777-64410 |
| 023. | [01] | 09646-60080 | SPRING | 22327-64400 |
Include in #3:
Cross reference number
| Part num | Firm num | Firm | Name |
| 09071-00230 | 22680-6440 | BELLOWS ASSY, PNEU | |
| 22680-64400 | TOYOTA | BELLOWS ASSY, PNEU |
