09010-07510 BODY ASSY, INJECTI Denso Cross




Information body assy, injecti

09010-07510 BODY ASSY, INJECTI
Rating:
29
Buy BODY ASSY, INJECTI 09010-07510 genuine, new aftermarket engine parts with delivery

KIT List:

Body assy, injecti 1904400460
Body assy, injecti 1904400460
Body assy, injecti 1904400460

Scheme ###:

BODY ASSY, INJECTI
000. [01] 09010-07510 BODY ASSY, INJECTI
001. [01] 09011-04060 HOUSING SUB-ASSY,
001-001. [03] 94904-30010 BOLT, STUD 94904-30010
002. [06] 09013-00300 HOLDER SUB-ASSY, D
003. [06] 09013-90050 O-RING
004. [06] 09013-60350 SPRING, DELIVERY V
006. [06] 09014-01750 VALVE SUB-ASSY, IN
007. [06] 09013-70120 GASKET, DELIVERY V
008. [06] 09015-04090 ELEMENT SUB-ASSY,
008. [06] 09015-04091 ELEMENT SUB-ASSY,
008. [06] 09015-04092 ELEMENT SUB-ASSY,
011. [06] 09043-60110 COVER, ELEMENT
011. [06] 09043-60181 COVER, ELEMENT
011. [06] 09043-60280 COVER, ELEMENT
012. [06] 94907-20780 RING, SNAP
013. [12] 94914-01120 O-RING
013. [12] 09013-90170 O-RING
014. [06] 09013-90040 O-RING
014. [06] 09013-90221 O-RING 09013-90221
016. [ C] 09043-80770 SHIM, ELEMENT HOLD
016. [ C] 09043-80780 SHIM, ELEMENT HOLD
016. [ C] 09043-80790 SHIM, ELEMENT HOLD
016. [ C] 09043-80800 SHIM, ELEMENT HOLD
016. [ C] 09043-80810 SHIM, ELEMENT HOLD
016. [ C] 09043-80820 SHIM, ELEMENT HOLD
016. [ C] 09043-80830 SHIM, ELEMENT HOLD
016. [ C] 09043-80840 SHIM, ELEMENT HOLD
016. [ C] 09043-80760 SHIM, ELEMENT HOLD
016. [ C] 09043-80750 SHIM, ELEMENT HOLD
016. [ C] 09043-80740 SHIM, ELEMENT HOLD
016. [ C] 09043-80080 SHIM, ELEMENT HOLD
016. [ C] 09043-80090 SHIM, ELEMENT HOLD
016. [ C] 09043-80100 SHIM, ELEMENT HOLD
016. [ C] 09043-80110 SHIM, ELEMENT HOLD
016. [ C] 09043-80120 SHIM, ELEMENT HOLD
016. [ C] 09043-80710 SHIM, ELEMENT HOLD
016. [ C] 09043-80720 SHIM, ELEMENT HOLD
016. [ C] 09043-80730 SHIM, ELEMENT HOLD
017. [12] 94901-17040 WASHER, STEEL PLAT
018. [12] 90258-10001 WASHER, SPRING 90258-10001
020. [01] 09021-00541 RACK ASSY, CONTROL
020-002. [02] 94904-43200 BOLT
020-004. [02] 94901-33990 WASHER, PLATE, SK
021. [02] 09011-40060 BUSHING, CONTROL R
022. [01] 94908-20290 PIN, STRAIGHT
023. [01] 09036-70010 BUSHING, CONTROL R
024. [06] 09016-00130 SLEEVE SUB-ASSY, C
025. [06] 09016-30060 SEAT, SPRING, UPR
026. [06] 09016-40260 SPRING, PUMP PLUNG
027. [06] 09016-50220 SEAT, SPRING, LWR
028. [06] 09017-00300 TAPPET SUB-ASSY,IN
028-001. [06] 09018-10210 ROLLER, INJECTION
028-002. [06] 09017-50050 SLIDER
028-003. [06] 09017-10310 TAPPET, INJECTION
028-004. [06] 09017-60080 PIN, INJECTION PUM 09017-60080
029. [01] 09019-11160 CAMSHAFT, INJECTIO
030. [01] 09036-10190 BEARING, CENTER
032. [02] 90015-06181 SCREW, SLOTTED OVA
032. [02] 94900-66510 SCREW
033. [01] 94910-10180 BEARING, ROLLER
034. [01] 09020-10680 COVER, BEARING
035. [01] 94915-02291 SEAL, OIL
036. [01] 09013-90110 O-RING
037. [ C] 09020-80280 PLATE, SHIM
037. [ C] 09020-80270 PLATE, SHIM
037. [ C] 09020-80260 PLATE, SHIM
037. [ C] 09020-80250 PLATE, SHIM
037. [ C] 09020-80240 PLATE, SHIM
037. [ C] 09020-80230 PLATE, SHIM
037. [ C] 09020-80220 PLATE, SHIM
038. [01] 09043-30030 RETAINER, BEARING
041. [01] 09031-70070 PLUG, SCREW
042. [06] 09031-70060 PLUG, SCREW
043. [01] 09027-10380 PLATE, INJECTION P
044. [12] 90045-06121 SCREW, SLOTTED POL
046. [01] 94910-10180 BEARING, ROLLER
048. [03] 94918-00310 SCREW, HOLLOW 94918-00310
058. [01] 09031-00280 VALVE ASSY, OVERFL
059. [10] 09022-20070 WASHER, FUEL PIPE 09022-20070
061. [02] 94904-71790 BOLT, W/WASHER
063. [01] 09010-60040 GASKET, FEED PUMP
063. [01] 94914-00380 O-RING
065. [01] 09027-20260 GASKET, INJECTION
066. [01] 94901-80710 WASHER, COPPER PLA
067. [06] 94901-81500 WASHER, COPPER PLA
070. [01] 09011-80360 NEEDLE, TIMING

Include in #3:

09010-07510 as BODY ASSY, INJECTI
19100-04002
19100-04012

Cross reference number



Part num Firm num Firm Name
09010-07510    BODY ASSY, INJECTI




Information:

start by:a) remove oil pan1. Turn the crankshaft until two pistons are at bottom center. Remove connecting rod caps (1) from the two connecting rods. Remove the lower half of the bearings from the caps.2. Push the connecting rods away from the crankshaft and remove the upper half of the bearings.
Be careful not to damage the crankshaft journals. Do not turn the crankshaft while any of the connecting rod caps are removed.
Install the bearings dry when the clearance checks are made. Put clean engine oil on the bearings for final assembly.3. Clean the surfaces where the bearings fit. Install the upper half of the bearing in the connecting rod. Pull the connecting rod slowly on to the crankshaft.4. Install lower half of the bearing in the cap.
When the connecting rod caps are installed, make sure that the numbers on the side of the caps are next to and respective with the number on the side of the connecting rods.
Typical Example5. Check the bearing clearance with Plastigage (A). Put Plastigage (A) on the bearing.6. Put 2P2506 Thread Lubricant on the threads of the rod bolts and seat surfaces of the nuts.
Do not use an impact wrench to tighten the nuts the additional 60 5°.
Do not turn the crankshaft when Plastigage (A) is in position. 7. Put caps (1) in position on the connecting rods and install the nuts. Tighten the nuts to a torque of 40 4 N m (30 3 lb.ft.). Put a mark on each nut and the end of each bolt. Tighten the nuts 60 5° more.8. Remove the cap. Measure the thickness of Plastigage (A). The rod bearing clearance must be 0.053 to 0.140 mm (.0021 to .0055 in.). The maximum permissible clearance is 0.15 mm (.006 in.).9. Put the caps in position on the connecting rods and install the nuts. Tighten the nuts to a torque of 40 4 N m (30 3 lb.ft.). Put a mark on each nut and the end of each bolt. Tighten the nuts 60 5° more.10. Do Steps 1 through 9 again for other bearings. end by:a) install oil pan
