154154-2400 ZEXEL 1424650015 BOSCH COILED SPRING 1541542400 1424650015

Essential Tools (For John Deere Starting Motor)
Commutator and Drive End Bushing Tools
Fig. 137-End Drive Bushing Removal and Installation Tool1 - 27487 - Handle - For removing and installing commutator and drive end bushings.2 - 27494 - Disk - For removing commutator and drive end bushing.27495 - Disk - For installing commutator and drive end bushing.3 - 27491 and 27492 - Disk Spacer - For removing and installing commutator and drive end bushing.4 - 27493 - Disk Pilot - For removing and installing commutator and drive end bushing.Center Bushing and Oil Seal Tools
Fig. 138-Center Bushing and Oil Seal Tools1 - 27487 - Handle - For installing center bushing and oil seal.2 - 27505 - Disk - For installing center bushing.3 - 27512 - Disk - For installing center oil seal.4 - 27501 - Disk Pilot - For installing center bushing and oil seal.JDE-80 - Starter Wrench - To remove and install rear mounting nut on starting motor.
Fig. 139-Starter WrenchConvenience Tools (For a Delco-Remy Starter)
Fig. 140-Armature Commutator Turning and Undercut ToolArmature Commutator Turning and Undercut Tool-Used to undercut armature and commutator.
Fig. 141-Pre-Lubricated Bushing ArborPre-Lubricated Bushing Arbor-To install prelubricated bushings.
Fig. 142-Spring Tension GaugeSpring Tension Gauge-To check brush spring tension.
