149162-0000 ZEXEL 1 464 695 013 BOSCH COILED SPRING 1464695013 1491620000

PARTS NEEDED
Qty
Part Number Description
6 1R6573 GASKET
1 2941706 GASKET
6 2941788 SEAL
1 2941790 PIPE
1 2941791 PIPE
1 2941792 PIPE
1 2941793 PIPE
1 2941794 PIPE
1 2941795 PIPE
6 2941803 SEAL-O-RING
6 3264700 INJECTOR GP-F -G
In order to allow equitable parts availability to all participating dealers, please limit your initial parts order to not exceed 2% of dealership population. This is an initial order recommendation only, and the ultimate responsibility for ordering the total number of parts needed to satisfy the program lies with the dealer.
ACTION REQUIRED
If your engine is experiencing a lack of power and/or black smoke emissions, complete the following action:
- Replace the six fuel injectors at the time of repair.
Refer to KENR8106, Disassembly and Assembly, for removal/install procedure of the fuel injector groups.
It is recommended that REBE9000, Service Letter, "Product Support Program For Reworking the Fuel Filtration System on Certain 320D and 323D Excavators", be performed at the same time as this Rework Procedure.
SERVICE CLAIM ALLOWANCES
Product smu/age whichever comes first Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
0-3500 hrs,
0-24 mo 100.0% 100.0% 0.0% 0.0% 0.0% 0.0%
3501-6000 hrs,
25-48 mo 33.0% 33.0% 25.0% 33.0% 25.0% 34.0%
This is a 4.0-hour job
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
