154620-8900 ZEXEL 9 421 612 434 BOSCH CLAMPING JAW 9421612434 1546208900

PARTS NEEDED
Qty
Part Number Description
1 1523968 SEAL-O-RING
1 2258019 GASKET-PUMP-HSG
1 2258287 GASKET-COVER
1 2744962 PUMP GP-F INJ -B
In order to allow equitable parts availability to all participating dealers, please limit your initial parts order to not exceed 3% of dealership population. This is an initial order recommendation only, and the ultimate responsibility for ordering the total number of parts needed to satisfy the program lies with the dealer.
ACTION REQUIRED
Replace failed injection pump with new pump.
Remove old pump using removal procedure as Disassembly and Assembly instruction SMCS 1251 - 011.
Install new Pump and replacement "O" Ring Seal as Disassembly and Assembly instruction SMCS 1251 - 012.
SERVICE CLAIM ALLOWANCES
Product smu/age whichever comes first Caterpillar Dealer Suggested Customer Suggested
Parts % Labor Hrs% Parts % Labor Hrs% Parts % Labor Hrs%
0-2000 hrs,
0-24 mo 100.0% 100.0% 0.0% 0.0% 0.0% 0.0%
This is a 3.0-hour job
PARTS DISPOSITION
Handle the parts in accordance with your Warranty Bulletin on warranty parts handling.
