150640-1100 ZEXEL 9 431 610 460 BOSCH BUSHING 9431610460 1506401100 6073170430

Polarity is negative ground.Rotation can be either direction.Output at 14 V and 2000 rpm (cold) ... 46 AOutput at 14 V and 5000 rpm (cold) ... 58 ARated output (hot) ... 65 AField current at 12 V and 80°F (27°C) ... 4.4 to 4.9 A(1) Four position cap for voltage adjustment.(2) Torque for pulley nut ... 75 5 lb. ft.(100 7 N m)(3) Torque for stud nut for battery connection ... 25 to 40 lb. in.(2.8 to 4.5 N m)5S6698 12V 75A (Delco-Remy Number 1117242)
Polarity is negative ground.Rotation can be either direction.Output at 5000 rpm (cold) ... 70 A *Rated output (hot) ... 75 AField current at 12 V and 80°F (27°C) ... 4.1 to 4.5 A*Fasten carbon pile to battery to get maximum output.(1) Torque for pulley nut ... 75 5 lb. ft.(100 7 N m)(2) Torque for stud nut for battery connection ... 9 to 11 lb. ft.(12 to 15 N m)2P1204 24V 19A (Prestolite Number ANB7002 or ANB7004)*
Polarity is negative ground.Rated output at 28V ... 19 AOutput at 1500 rpm and 28V ... 10 AResistance of the rotor at 77°F (25°C) ... 18 to 20 ohmCurrent consumption (draw) at 77°F (25°C) and 24V ... 1.20 to 1.33 A(1) Torque for nuts holding pulley ... 75 5 lb. ft.(100 7 N m)(2) Torque for nuts for terminals for field and ground ... 25 to 30 lb. in.(2.8 to 3.4 N m)(3) Torque for screws holding terminal plate ... 10 to 15 lb. in.(1.1 to 1.7 N m)(4) Torque for bolts ... 25 to 30 lb. in.(2.8 to 3.4 N m)(5) Torque for bolts holding regulator ... 45 to 50 lb. in.(5.1 to 5.7 N m)(6) Torque for nut for terminal ... 45 to 50 lb. in.(5.1 to 5.7 N m)(7) Torque for nut for positive terminal ... 225 to 250 lb. in.(25.4 to 28.3 N m)2P1699 Regulator (Prestolite Number VSH-6401A)4N5938 Regulator (Prestolite Number VSH-6401B)6N3821 Regulator (Prestolite Number VSH-6401C)*Including:
