Information autom. advance mechanism
BOSCH
9 420 616 529
9420616529
ZEXEL
102753-0001
1027530001
Rating:
Scheme ###:
| 1. | [1] | 137502-1100 | FLANGE BUSHING |
| 2. | [1] | 137502-1620 | FLYWEIGHT ASSEMBLY |
| 2. | [1] | 137502-1620 | FLYWEIGHT ASSEMBLY |
| 8. | [2] | 156703-0500 | ECCENTRIC DISC |
| 8. | [2] | 156703-0500 | ECCENTRIC DISC |
| 9. | [2] | 156703-0600 | ECCENTRIC DISC |
| 9. | [2] | 156703-0600 | ECCENTRIC DISC |
| 11. | [1] | 156701-0020 | FLANGE BUSHING |
| 12. | [1] | 137502-0800 | SHIM |
| 13. | [1] | 137502-0120 | SHIM |
| 16. | [1] | 137502-0900 | PLAIN WASHER |
| 17. | [1] | 156709-1000 | LOCKING WASHER |
| 18. | [1] | 131325-3201 | UNION NUT |
| 19/1. | [0] | 156708-1800 | SHIM D104&26.2T1.9 |
| 19/1. | [0] | 156708-1900 | SHIM D104&26.2T2.0 |
| 19/1. | [0] | 156708-2000 | SHIM D104&26.2T2.1 |
| 20. | [1] | 016020-2620 | LOCKING WASHER |
| 21. | [1] | 137502-1900 | TOOTHED GEAR |
| 22. | [6] | 137502-1300 | BLEEDER SCREW |
| 23. | [1] | 137502-1000 | UNION NUT |
| 24. | [1] | 137502-1200 | LOCKING LEVER |
| 25. | [6] | 137502-1400 | PLAIN WASHER |
| 26. | [6] | 014110-6440 | LOCKING WASHER |
Cross reference number
Zexel num
Bosch num
Firm num
Name
102753-0001
AUTOM. ADVANCE MECHANISM
Q 14KJ AUTOMATIC TIMER TIMER SCDM TIMER
Q 14KJ AUTOMATIC TIMER TIMER SCDM TIMER
