159601-5121 ZEXEL 9 421 621 083 BOSCH ADJUSTING DEVICE 9421621083 1596015121 227101950a




Information adjusting device

BOSCH 9 421 621 083 9421621083
ZEXEL 159601-5121 1596015121
HINO 227101950A 227101950a
159601-5121 ADJUSTING DEVICE
Rating:
19
Buy ADJUSTING DEVICE 159601-5121 zexel genuine, new aftermarket engine parts with delivery

Scheme ###:

1. [1] 159598-4720 DIAPHRAGM HOUSING
2. [6] 159596-2800 BLEEDER SCREW
3. [1] 159610-1400 SEAL RING
5. [1] 131420-0400 BLEEDER SCREW
6. [1] 026506-1040 GASKET D9.9&6.2T1
8. [2] 139514-0300 GASKET
9. [1] 029731-4680 EYE BOLT
15. [1] 159605-4121 ACTUATOR
16. [1] 159610-1300 SEAL RING
17. [4] 010206-3040 HEX-SOCKET-HEAD CAP SCREW M6P1L30
17. [4] 010206-3040 HEX-SOCKET-HEAD CAP SCREW M6P1L30
18. [1] 139306-0400 PLAIN WASHER
19. [4] 029320-6010 LOCKING WASHER
19. [4] 029320-6010 LOCKING WASHER
20. [3] 159595-5700 PLAIN WASHER
800S. [1] 159595-8801 COVER
801S. [1] 159610-1200 SEAL RING
802S. [4] 010206-3040 HEX-SOCKET-HEAD CAP SCREW M6P1L30
803S. [4] 029320-6010 LOCKING WASHER

Include in #1:

Cross reference number

Zexel num
Bosch num
Firm num
Name
159601-5121
9 421 621 083
227101950A  HINO
ADJUSTING DEVICE
K 74HA ACTUATOR ASSY FUN ACT
